Home > Kaba E-Plex® 5200 Stand-alone Access Control Lock, PC Programmable

Simple.  Smart.  Scalable.  Upgrading your traditional key locks or mechanical push-button locks is easier than ever with the E-Plex® 5200 Series.  This lock combines the strength, simplicity, and reliablity of the distinguished Kaba Simplex,® with the enhanced security and convenience of stand-alone electronic access control.  You and your staff can now use secure codes for access.  And since this is auto-locking, you can be assured that doors will always be locked.  This adds another layer of security to protect confidential and/or private information in the spaces behind those doors.  Does this lock require AC/DC current?  Nope.  It's fully battery powered, saving you on the overall costs of implementation and installation.  You can be up and running in less than hour time.  "I've never heard of Kaba, who are they?"  Glad you asked!  Kaba has been around since the 1800's making first-class locking technologies.  They are the largest provider of access control products in the world.

Features

• Heavy Duty - ANSI/BHMA Grade 1, stand-alone access control lock
• Cylindrical latchbolt locking mechanism (latch includes a 1/4" deadlocking plunger bolt to prevent jimmying of door)
• Supports 3000 users per door; 4-8 digit user access codes (100 million possible code combinations)
• Network and PC Programming (offline):  Requires laptop/netbook (mini-laptop) and E-Plex Enterprise Implementation Kit (sold separately at checkout)
• Time-Determined Access:  Via software, program up to 16 different access schedules, and up to 32 holiday/vacation time blocks (i.e., door auto-unlocks at 9am, and auto-locks at 6pm, or users in group 1 only have access from 10am to 4pm)
• First Manager In Feature:  Lock does not go to passage mode (enter without code) until the first privileged user's credential is presented
• Passage mode can be manually toggled at the lock
• 6 different authority access levels let you determine who has privileges to specific lock functions
• Tested extensively in outdoor and marine environments; performed flawlessly
• Track entries of who entered and when with audit trail feature (reader unit stores last 30,000 events)
• Quick and Easy Installation:  Patented electrobolt  technology provides "sandwich" fitting.  No wiring to or through door; no risk of pinched wires.  Instructions and two-hole drilling template supplied
• Out of the Box Ready:  Programming and operating manuals provided
• Optional remote unlock feature
• Emergency Key Override:  Universal 6 pin cylinder (common for commercial applications) with Schlage C keyway provided.  Two nickel silver keys, and 4 additional tailpieces (part that connects outside lock to inside lock) included.  These tailpieces allow you to use other name brand cylinders in the lock should you choose
• Three year manufacturer's warranty; built-in warranty counter

Specs

• Dimensions:  Exterior - 8 7/8" H x 3 3/8" W x 3 13/16" D, Interior - 8 7/8" H x 3 13/16" W x 2 1/8" D
• Backset Size:  2 3/4" backset included (2 3/8" available at checkout)  - How do I measure?
• Door Thickness:  1 3/8" ~ 2 1/4" thick
• Handing:  Non-handed, fits virtually all left and right swing doors
• Battery operation:  Up to 180,000 cycles on 4 AA alkaline batteries, included.  Batteries located in interior housing cover.  Low battery indicator.  Non-volatile memory; lock's data preserved if batteries fail
• Operating Temperature Range:  -31 F ~ 151 F for exterior lock housing.   -31 F  ~ 130 F for interior housing
• Fire Rating:  3-hour UL/ULC (underwriter's laboratory / underwriter's laboratory Canada)
• Finish:  Choose from multiple architectural finishes including standard satin chrome (626) and premium finishes.  Premium finishes may be subject to 2-3 week lead time

Download the product FAQ (pdf)
