Kaba E-Plex E5086
Entry/Exit (Back-to-Back) Pushbutton Lock
$1,434.51 – $1,508.76
The Kaba E-Plex E5086 combines the strength, simplicity, and reliability of the distinguished Kaba Simplex, with the enhanced security and convenience of stand-alone electronic access control. You and your staff can now use secure codes for access. Since this is auto-locking, you can be assured that doors will always be locked.
Need assistance or have questions? Call our Cabinet Product Specialists at 877-439-5377 for more information and ordering assistance. We’re here to help!
Need assistance or have questions? Call our Commercial Product Specialists at 877-439-5377 for more information and ordering assistance. We’re here to help!
- Heavy Duty – ANSI/BHMA Grade 1, stand-alone entry/exit access control lock
- Mortise locking mechanism
- Supports 100 users on both sides; 4-8 digit user access codes (100 million possible code combinations)
- Easy programming via keypad or PC using optional E-Plex Software Implementation Kit (available at checkout)
- PC management simplifies administration of doors and users as facility’s number of personnel and access points grow
- Records a time/date stamp (audit trail) of when user’s accessed your door. Downloads into easy to use reports. Requires E-plex 300 Software Implementation Kit (sold separately)
- 3 operating modes: PIN code entry, lockout, or passage mode (you can toggle the passage mode, or program it so the door re-locks after certain number of hours [1-24])
- 5 authority access levels let you determine who has privileges to specific lock functions
- Battery Operation: 4 AA alkaline batteries included. Batteries located in interior housing cover. Low battery indicator. Non-volatile memory; lock’s data preserved if batteries fail
- Tested extensively in outdoor and marine environments – performed flawlessly
- fits virtually all left and right swing doors
- Choose from 6 architectural finishes – premium finishes may be subject to 2-3 week lead time, including; bright brass (605), satin brass (606), bright chrome (625) and dark bronze with brass accents (744)
- 3,000 event audit trail on both sides
- Quick and easy installation. Patented electrobolt technology provides “sandwich” fitting. No wiring to or through door; no risk of pinched wires. Instructions and two-hole drilling template supplied
- Out of the box ready – programming and operating manuals provided
- Emergency key override using universal 6 pin cylinder (common for commercial applications) with Schlage C keyway. Two nickel silver keys, and 4 additional tailpieces (part that connects outside lock to inside lock) included. These tailpieces allow you to use other name brand cylinders in the lock should you choose Need this same lock with IC or Removable core? Click here
- 1-year manufacturer warranty; built-in warranty counter
Outclasses. Outlasts. Outperforms. Upgrading your airport jet-way, police interrogation room, mental health facility or other locks is easy with the E-Plex 5086 double-sided. This two-way access control system combines the strength, simplicity, and reliability of the distinguished Kaba Simplex, with the enhanced security and convenience of stand-alone electronic access control. You and your staff can now use secure codes for access. And since this is auto-locking, you can be assured that doors will always be locked. This adds another layer of security to protect confidential and/or private information in the spaces behind those doors. Does this lock require AC/DC current? Nope. It's fully battery powered, saving you on the overall costs of implementation and installation. You can be up and running in less than hour time. "I've never heard of Kaba, who are they?" Glad you asked! Kaba has been around since the 1800's making first-class locking technologies. They are the largest provider of access control products in the world.| Exterior Dimensions | 8 7/8 (H) x 3 3/8 (W) x 3 13/16 (D) in. |
|---|---|
| Inside Dimensions | 8 7/8 (H) x 3 3/8 (W) x 3 13/16 (D) in. |
| Mortise Casing Dimensions | 5 7/8 (H) x 4 1/8 (W) in. |
| Faceplate Size | 8 (H) x 1 1/4 (W) in. |
| Door Thickness Minimum | 1 3/4 in. |
| Door Thickness Maximum | 2 1/4 in. |
| Battery Type | AA |
| Battery Life | 100,000 Cycles |
| Code Length | 4 to 8 Digits |
| Code Capacity | 100 |
| Event Audit Trail | 3,000 |
| Environmental | Indoor/Outdoor |
| Outside Operating Temperature Range | -31° to 151°F (-35° to 66°C) |
| Inside Operating Temperature Range | -31 °F to +130 °F (-35 °C to 55 °C) |
| Construction | Solid cast housings, Solid cast, ADA-compliant levers |
| Door Handing | Non-Handed |
| Door Prep | Mortise, Through-Bolt Hole(s) |
| Door Stile Width | Minimum 5 in. |
| Manufacturer | dormakaba |
| Brand | Kaba E-Plex |
| Lock Features | Audit Trail, Double-Sided, Passage Mode |
| Handle Type | Lever Handle Door Locks |
| Locking Device | Mortise |
| Door Opening | Standard |
| Access Type | Key, Keypad – Digits |
| Fire Rating | 3-hour UL/ULC fire rating for A labeled doors |
| ANSI Rating | Grade 1 (Best) |
| BHMA Rating | Grade 1 (Best) |
| Authentication | Single Factor |
| Weight | 15.7 lbs |
| Warranty | 1 Year Manufacturer |
Share your thoughts!
Let us know what you think...
What others are saying
Customer Questions & Answers
There are no questions yet. Be the first to ask a question about this product.
Becca (verified owner) –
I installed this lock around November 2017. In that time, the batteries failed twice! Supposedly they are supposed to last for at least 3 years! The first time, the company shipped us a replacement set. It took a long time, but it finally arrived. Now it is January 2019 and I’m about to contact them again for ANOTHER replacement set. I had to put up a lock box so people could get the key to unlock the gate. Kind of pointless and asinine….
