Kwikset SmartCode 917

Traditional Electronic Keypad with Tustin Lever


Be smart about your security. The Kwikset SmartCode 917 provides keyless entry with impeccable style. Designed with the highest residential security grade to keep your home protected. Best uses include home office doors, laundry rooms, interior garage doors and more.

Your Current Selections:
Your Current Selections:

For more information or ordering assistance, please call our Residential Product Specialists at 877-439-5377

  • Ideal for Home offices, side doors, interior garage doors, storage closets, rental properties and more
  • Traditional style with Tustin lever – Contemporary style with Halifax lever available
  • Reversible lever
  • 30 user codes and one programming code for lock management
  • Programmable one-time user code for emergencies, which deletes after first usage
  • Auto-Lock
  • Passage mode
  • Disable passage
  • Disable keypad for privacy
  • SmartKey Security to protect against advanced break-in techniques
  • BHMA Class AAA Highest Residential Rating
  • UL Fire rating for 20 minutes
  • 3-year battery life

Note: This product replaces the discontinued Kwikset SmartCode 911.

The Kwikset SmartCode 917 provides keyless entry with impeccable style. Designed with the highest residential security grade to keep your home protected. Best uses include home office doors, laundry rooms, interior garage doors and more. Featuring Auto-lock, passage mode, and the ability to disable passage and the keypad for privacy. The Auto-lock feature can be enabled to automatically lock your door behind you after a preset amount of time, perfect for times when you have your hands full. Passage mode enables guests to freely access your door during a party or gathering without having to enter the code each time. Disabling Passage mode is useful for property managers to set the lock to auto-lock every time with a key or code always required for entry. This ensures temporary staff or caretakers do not forget to lock utility rooms or other restricted areas of your home or rental property. Up to 30 user codes can be used with the lock, so pass them out to friends, family or the cable repairman. All lock management can be done using the programming code. The programming code enables you to make changes without needing to access the interior program button. If enabled, just press the Kwikset button on the lock and make your changes. Kwikset’s patented Smartkey security function helps protect against advanced break-in techniques. It’s time to bid farewell to keys and go keyless with the Kwikset Smartcode 917.

Exterior Dimensions

5 5/32 (H) x 5 19/32 (W) x 3 3/32 (D) in.

Inside Dimensions

5 3/8 (H) x 5 5/8 (W) x 2 29/32 (D) in.

Door Thickness Minimum

1 3/8 in.

Door Thickness Maximum

1 3/4 in.

Code Length

4 to 8 Digits

Code Capacity


Battery Type


Battery Life

3 Years




Front body: Weather Resistant

Outside Operating Temperature Range

-40°F to 150°F

Inside Operating Temperature Range

32°F to 130°F

Door Handing


Door Prep

Standard 2 1/8 in. Cross-Bore, Edge Bore: 1 in.

Door Stile Width

Minimum 4 in.

Door Opening


Locking Device

Cylindrical Latch

Lock Features

Auto Relocking, Auto Unlocking, Passage Mode, Privacy, Tamper Alerts

Access Type

Keypad – Digits






Kwikset Recodeable (KW1)

ANSI Rating

Grade 2 (Better)


3.70 lbs


1 Year Electronic, Lifetime Mechanical and Finish

Share your thoughts!

Let us know what you think...

What others are saying

There are no contributions yet.




Creating an account will allow you to easily place repeat orders, track them, and get first access to promotions and discounts!

Your privacy — along with your trust in our products and service — is very important to us. Rest assured GoKeyless RESPECTS your privacy. privacy policy

Continue as a Guest

Don't have an account? Sign Up

Customer Questions & Answers

  1. Q Does this unit have any Bluetooth capability? answer now
    Asked by Georg on January 1, 2023 4:08 PM

    No, this lock is not Bluetooth compatible.

  2. A

    This model would replace your standard door knob for PIN code or keyed entry. The SmartCode 917 includes both the exterior and interior handles.

  3. Q Can this be used on an exterior door, subject to theweather? answer now
    Asked by Tony on February 1, 2022 5:14 PM

    This lock is weather resistant.

  4. Q How do you change the battery? answer now
    Asked by irene Rodriguez on August 26, 2021 4:01 PM

    This is as simple as sliding the interior cover upward and exchanging the 9V battery inside. If the optional security screw was installed, the interior unit will need to be removed to access the battery compartment.

  5. A

    Yes, it certainly can be rekeyed to match your existing Kwikset keys!

  6. Q My Lock did not come with directions in English. answer now
    Asked by Patrick G Hirtz on December 30, 2020 2:48 PM

    Please use the link below to download a copy of the Smartcode 917 manual for your records.

    Kwikset Smartcode 917 Manual
