dormakaba Saffire EVO LZ-M

Name: dormakaba Saffire EVO LZ-M
SKU: EMLW2-EKECB-PETCB-11L
Availability: InStock

Electronic Mortise Lockset

SKU: EMLW2-EKECB-PETCB-11L

Call For Price Contact For Pricing

Features
Description
Specifications

Saffire EVO LZ-M Data Sheet

Wi-Fi Network Minimum Requirements

The EVO LZ series requires a 3rd party aggregator for integration with Lyazon, such as:
ButterflyMX

Special project pricing is available. Contact us today to take advantage of exclusive offers tailored to your business. Let us help you find the perfect solution for your needs.

Applications

Ideal for new construction projects or when doors are being replaced
Simplified door preparation for ease of installation
Suitable for small to very large-scale properties
Access control for tenant rooms, common areas, and back-of-house
Ideal for multi-housing projects, including apartments, student housing and more

Features

• Get real-time notifications, including events and access anomalies

• Manage access rights to allow or revoke access for residents and visitors in real-time, from anywhere

• Easily send digital keys or PIN codes to residents and visitors from a mobile device• Allow residents to use their mobile device, RFID credentials or PIN to access their residence or common areas

• Provide convenient one-time or recurring access PINs to service and maintenance personnel

• Control when and where residents and visitors can go throughout the building

• Quickly delete lost access media to keep the building secure.

Security features

• Online connectivity ensures continuous

firmware updates for increased device

security

• BHMA A156.36 Grade 2

• UL 10C 3-hour fire rating

• Non-volatile memory maintains lock

programming and audit records

• Tamper-proof design

• No need to visit the lock to update access

The Saffire EVO LZ Series are cloud-connected locks that combine high performance with aesthetics that seamlessly integrate with building technology providers and amenities for multi-housing properties. The Saffire EVO LZ locks provide an easy-to-use, secure, and flexible solution with the benefits of real-time connectivity. They include the convenience of using either mobile devices, RFID credentials, or secure PINs for access to resident units, common areas, and perimeter doors.

Basic

Manufacturer	dormakaba USA Inc.
ANSI Rating	ANSI/BHMA A156.13 Grade 1 mortise lock
Battery Type	3 AA
Lock Features	Audit Trail, Auto Relocking, No Tour, Passage Mode
Warranty	2 Years (Mechanical & Electrical)
Access Type	Keypad - Digits Smart Card/Fob Smartphone/App
Locking Device	Mortise
Brand	dormakaba Saffire

Door requirements

Door Handing	Field-reversible (left or right factory-handed mortise)
Battery Life	13 months. Low-battery indicator to help with preventative maintenance. It is visible on the device and has an event notification in the system. Passive waring and notification
Door Prep	Deadbolt
Environmental	-31°F to 158°F (-35°C to 70°C), 0% to 90% non-condensing humidity at 86°F (30°C) meets IP54

Security

Credential Format	Dormakaba ComID (13.56MHz MIFARE DESFire EV2/EV3 ISO card/fob/BLE/PIN)
Credential Type	Card, Fob, MIFARE
Fire Rating	Meets UL 10C and ULC S-104 (fire doors up to 3 hours)
Wireless Protocol	Wi-Fi 2.4GHz (802.11 b/g/n), WPA2, WPA AES 128, TLS 1.2

Dimensions

Exterior Dimensions	6 (H) x 2.56 (W) x 3.50 (D) in.
Door Thickness Minimum	1 3/8"
Door Thickness Maximum	2 1/2"(35mm to 64mm)
Backset	2 3/4" (70mm) adjustable
Certifications	IC RSS-130/133/139/247, ADA, CAN/ULC-S104, FCC Part 15, Florida Building Code, UL 10C
Exterior Dimensions	6 (H) x 2.56 (W) x 3.50 (D) in.
Lock Dimensions	5.5 (H) x 2.63 (W) x 1.76 (D) in.
Temperature Range	-31°F to 158°F (-35°C to 70°C)
