  • Schlage LEBMB-GRW

    Mobile Enabled Mortise Privacy Lock with ENGAGE

    SKU: LEBMB-GRW-P-07-626-00A-RH-10-136-134-S123

    Schlage and Schlage ENGAGE Locks Products

    Discover the added protection of antimicrobial finishes for this product! For more information and assistance with placing an order, please don't hesitate to give us a call. Our team is ready to help you find the perfect solution.

    Connect directly to smart phones and tablets for wireless setup and configuration! Ideal for commercial, education and multifamily applications.  With your smartphone and the new Schlage Mobile Access Credentials you can extend your electronic access control affordably, without keys or wires!

    Quantity left : 0



    3 Years of SHIELD Coverage

    Product Replacement | Extended Return Policy | Price Protection

    Terms and Conditions


    Call For Price

    NEW – Bluetooth Mobile Access

    • LEBMB Mobile enabled mortise with interior push button – standard and deadbolt models also available
    • New LEB option is ready for the future with the ability to read Bluetooth and NFC mobile credentials
    • Compatible with new Schlage Mobile Access Credentials (see tab for more details)
    • Supports Mobile Student IDs in Apple Wallet (LE and LEB)
    • Quick response from smart device to mobile enabled lock or reader
    • Unlock an opening from up to 30 feet away
    • Best-in-class asymmetric credential encryption
    • Anti-theft biometrics using the phone’s fingerprint or facial recognition features
    • Works without internet connection or cellular service at the opening

    Already have a LE Series lock but are looking to upgrade to Bluetooth mobile access? New retrofit upgrade kits are available! Please call for details.

    Schlage LE Series

    • Designed to be easy to install, connect, manage, and use
    • Available with indicator, interior push button, or deadbolt for storeroom, privacy, apartment, and office applications
    • Built-in Wi-Fi® enables automatic daily updates (once every 24 hrs) sent directly from host software
    • Built-in Bluetooth® enables wireless configuration from smart phones and tablets
    • Networked real-time communication available with the ENGAGE Gateway and PACS provider solutions
    • Weather resistant design for use on perimeter doors
    • Suites with mechanical L Series with 31 levers and two knobs
    • Compatible with most proximitySchlage fobsSchlage smart cards
    • Works with same credential used on the building perimeter; smart credentials can be used for vending and other applications
    • Innovative door position sensor built right into the lock and strike-plate
    • Battery Operation:  Up to 2 years of battery life on 4 AA (included)
    • Manage from ENGAGE website or Free ENGAGE app available on iTunes and Google Play
    • Greenwich Trim sectional style and rose with Sparta lever design
    • ANSI/BHMA: Grade 1
    • Mortise mounting style with Armor front and LED indicator. Also available in cylindrical mounting style
    • Built on proven Schlage L Series, Grade 1 mechanical lock
    • Fits existing mechanical mortise preps with no wires with only minor modifications
    • Standard Strike: 1-1/4″ x 4-7/8″ square corner, 1-3/16″ lip with box and DPS.  Additional strikes, lip lengths and ANSI strike box available upon request
    • Standard Key Override: Schlage 6-pin Everest 29 S123 keyway mortise cylinder with two patented keys. Additional keying options available, including standard and interchangeable cores, competitor brands, master keying and grand master keying

    App Features

    • Add and configure devices
    • Add new users and enroll credentials
    • View audits and alerts by door
    • User schedules, device schedules, including auto-unlock and auto-lock times (30 min. increments), and holiday time zone capability
    • Perform lock diagnostics
    • Send updates to devices anytime via Bluetooth at the lock, or from the Allegion cloud server via WiFi once every 24 hrs.
    • Requirements: iOS 7.1 or later. Android 4.4 (Kit Kat) or later


    • Compatible with any Android or iOS that supports native NFC technology. This includes the iPhone 6 and newer, Galaxy S3 and newer.

    Product FAQ

    This page is for the stocked model. We accept custom orders! To see the options, download the Ordering Guide, then contact us for a quote.

    GoKeyless is a trained and authorized Schlage® dealer. Sales, service, and support. It's why thousands of clients around the world choose GoKeyless™ for their security and access control needs each year.

    The new Schlage LE Series wireless lock with ENGAGE technology is designed to be easy to install, connect, manage and use. Developed specifically for facilities that want to upgrade to electronic or Schlage Mobile Access credentials for improved security and efficiency, it is ideal for interior office doors, common area doors and sensitive storage spaces with a cylindrical door prep.

    LE Series wireless mortise locks simplify installation by combining the lock, credential reader, door position sensor and request-to-exit switch all in one unit. LE wireless locks utilize the standard mechanical lock mortise door prep and can be installed in 30 minutes or less with only minor modifications.

    The new Schlage Mobile Access Credentials enable residents or staff members to utilize a mobile device instead of a physical badge to securely unlock an opening. Available for iOS and Android phones, the Schlage Mobile Access Credential app is convenient and easy to use. Simply select a specific door listed on the app. Once access is granted, the encrypted unlock signal will be sent from the smart device to the mobile enabled lock or reader.

    ENGAGE cloud-based web and mobile apps make it easy to configure lock settings, add users, create user time zones and lock schedules, and view audits and alerts from anywhere. For advanced wireless capabilities and increased user and schedule capacity, LE Series wireless locks can be managed with software from Schlage’s access control alliance partners. LE Series wireless locks can be updated manually at the lock with the ENGAGE mobile app, automatically daily over WiFi or in real time when connected to an alliance partner gateway.

    LE Series wireless locks with ENGAGE technology are compatible with most proximity, Schlage fobs, and Schlage smart cards.


    Manufacturer Allegion
    ANSI Rating Grade 1 (Best)
    Battery Type AA
    BHMA Rating Grade 1 (Best)
    Finish Satin Chrome
    Lock Features Old Audit Trail, Bluetooth, No Tour, Passage Mode, Privacy, Remote Control
    Solution Electronic
    Warranty 1 Year Manufacturer
    Function Apartment
    Handle Type Lever Handle Door Locks
    Access Type Key
    Proximity Card/Fob
    Smart Card/Fob
    Locking Device Mortise
    Brand Schlage
    Schlage ENGAGE Locks Products

    Door requirements

    Door Handing Reversible
    Battery Life 2 Years
    Battery Temperature Range 32° to 120°F (0° to 49°C)
    Door Prep Mortise, Through-Bolt Hole(s)
    Lever Design Sparta


    Scanning Time ≤ 1 sec.
    Users 5,000
    Wireless Protocol Bluetooth BLE, IEEE 802.11b/g, WiFi
    Wireless Range 100 ft.


    Exterior Dimensions 8.181 (H) x 2.125 (W) x 2.903 (D) in.
    Inside Dimensions ["9.658 (H) x 3.00 (W) x 2.498 (D) in."]
    Door Thickness Minimum 1 3/4 in.
    Backset 2 3/4 in.
    Door Stile Width Minimum 5 in.
    Exterior Dimensions 8.181 (H) x 2.125 (W) x 2.903 (D) in.
    Weight 10 lbs
