Linear MiniMax 3

Single Door Access Control System

$594.99 See Price

PC software online managed access of doors and users.

In stock

Your Current Selections:
SKU: 0-205672
  • Accommodates up to 2,000 users per door
  • Network-ready, In/Out access control using keypads and readers, which connect directly to the MiniMax 3
  • Compatible with IEI Keypads, and Wiegand and IEI Readers)
  • Supports sounder and LED control
  • Managed using Hub Manager software (features include system dashboard, time and attendance, unlimited operators, password protection, management reports, setup wizard, 2,000 transactions buffered in audit trail, first-in auto unlock)
  • Communicate with MiniMax 3 controller from a laptop via a USB serial connection, or from PC/Network PC via LAN/WAN (LAN/WAN requires SEG-M plug-in gateway)
  • Continues to operate normally during data import or system export
  • Outputs for forced door, propped door, and alarm shunt to tie-in to new or existing fire alarm and security systems
  • Inputs for door monitor and request to exit
  • Enclosure Size: 11.5” H x 11.5” W x 3.75” D
  • Environmental: Operating temperature: -20°F to 130°F (-28°C to 54°C)

Package Contents:
(1) Max 3 Module
(1) MiniMax 3 Backplane
(1) Auxiliary Device Power Supply (powers keypad/reader)
(1) Enclosure with Cam Lock
(1) Programming Keypad (manual setup)

Wiring Requirements:
Maximum Distances with shielded:18 AWG20 AWG22 AWG
Controller to reader/keypad1000ft500ft250ft
Controller to controller1000ft500ft250ft
Controller to PC or Printer1000ft500ft250ft
You free up time and save your business money by eliminating the distribution, tracking, and collecting of keys when you invest in this online access control system by IEI. With one click of your mouse you can remotely open and update your door(s); your receptionist can buzz visitors in, and you can quickly change the access rights to your doors when an employee leaves.  Compact in size, we recommend this access control system for small to mid-size applications.  Typically installed at the door above the ceiling over the door, the MiniMax 3 pairs with electric strikes and maglocks, as well as wiegand supported readers (formats up to 39 bits), and IEI keypads/card readers.  You can create a PIN, card, or PIN followed by card access control system.  The MiniMax 3 backplane includes a power supply for your keypad/reader.  You want to use a separate power supply for your electric strike or mag lock.  We like the Securitron BPS.  Setup and management of your door is easily accomplished by using Hub Manager Professional software.  And getting your new MiniMax 3 up and running is not difficult, it simply requires a small investment of time.  You simply load the software onto your network, and follow the setup wizard for bringing your door online.  You can also communicate to the MiniMax via a direct PC connection.  You will need the USB-Serial adapter to do this.  Once you enter your users into the software's database, and assign the time(s) for access, you are done and can begin using the system.  Designed for single door applications, you can also network the Mini Max 3 with other Mini Max 3 controllers, or Max 3 Access Systems to achieve managed access for up to 64 doors per site, up to 999 sites, and up to 20,000 total users - system wide.
Manufacturer

Nortek

Brand

Linear
